android kotlin - File provider image share internal storage

MainActivity.kt

package com.cfsuman.jetpackexamples

import android.graphics.BitmapFactory
import androidx.appcompat.app.AppCompatActivity
import android.os.Bundle
import android.widget.Toast
import kotlinx.android.synthetic.main.activity_main.*


class MainActivity : AppCompatActivity() {

    override fun onCreate(savedInstanceState: Bundle?) {
        super.onCreate(savedInstanceState)
        setContentView(R.layout.activity_main)

        // Share button click listener
        btnShare.setOnClickListener{
            // Get bitmap from drawable resource
            val bitmap = BitmapFactory.decodeResource(resources, R.drawable.animal)

            // Save the bitmap to internal storage and get uri
            val uri = bitmap.saveToInternalStorage(this)

            // Toast the uri internal storage saved bitmap
            Toast.makeText(applicationContext,uri.toString(),Toast.LENGTH_SHORT).show()

            // Finally, share the internal storage saved bitmap
            this.shareCacheDirBitmap(uri)
        }
    }
}
activity_main.xml

<?xml version="1.0" encoding="utf-8"?>
<androidx.constraintlayout.widget.ConstraintLayout
    xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:app="http://schemas.android.com/apk/res-auto"
    xmlns:tools="http://schemas.android.com/tools"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    tools:context=".MainActivity">

    <ImageView
        android:id="@+id/imageView"
        android:layout_width="0dp"
        android:layout_height="250dp"
        android:layout_marginEnd="8dp"
        app:layout_constraintEnd_toEndOf="parent"
        app:layout_constraintStart_toStartOf="parent"
        app:layout_constraintTop_toTopOf="parent"
        app:srcCompat="@drawable/animal" />

    <Button
        android:id="@+id/btnShare"
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:layout_marginStart="8dp"
        android:layout_marginTop="8dp"
        android:layout_marginEnd="8dp"
        android:text="Share Image"
        app:layout_constraintEnd_toEndOf="parent"
        app:layout_constraintStart_toStartOf="parent"
        app:layout_constraintTop_toBottomOf="@+id/imageView" />

</androidx.constraintlayout.widget.ConstraintLayout>
Extensions.kt

package com.cfsuman.jetpackexamples

import android.app.Activity
import android.content.Context
import android.content.ContextWrapper
import android.content.Intent
import android.graphics.Bitmap
import android.graphics.BitmapFactory
import android.graphics.Canvas
import android.net.Uri
import android.view.View
import androidx.core.content.FileProvider
import java.io.*


// Extension function to share save bitmap in cache directory and share
fun Activity.shareCacheDirBitmap(uri: Uri){
    val fis = FileInputStream(uri.path)  // 2nd line
    val bitmap = BitmapFactory.decodeStream(fis)
    fis.close()

    try {
        val file = File("${this.cacheDir}/drawing.png")
        bitmap.compress(Bitmap.CompressFormat.PNG, 100, FileOutputStream(file))
        val contentUri = FileProvider.getUriForFile(this, this.packageName + ".provider", file)

        val shareIntent = Intent()
        shareIntent.action = Intent.ACTION_SEND
        shareIntent.putExtra(Intent.EXTRA_STREAM, contentUri)
        shareIntent.type = "image/*"
        this.startActivity(Intent.createChooser(shareIntent, "Share Image"))
    } catch (e: FileNotFoundException) {
        e.printStackTrace()
    }
}


// Extension property to get bitmap from view
val View.bitmap: Bitmap
    get() {
        // Screenshot taken for the specified root view and its child elements.
        val bitmap = Bitmap.createBitmap(this.width, this.height, Bitmap.Config.ARGB_8888)
        val canvas = Canvas(bitmap)
        this.draw(canvas)
        return bitmap
    }



// Extension method to save bitmap to internal storage
fun Bitmap.saveToInternalStorage(context: Context): Uri {
    // Get the context wrapper instance
    val wrapper = ContextWrapper(context)

    // Initializing a new file
    // The bellow line return a directory in internal storage
    var file = wrapper.getDir("images", Context.MODE_PRIVATE)


    // Create a file to save the image, random file name
    //file = File(file, "${UUID.randomUUID()}.png")

    file = File(file, "image.png")

    try {
        // Get the file output stream
        val stream: OutputStream = FileOutputStream(file)

        // Compress bitmap
        this.compress(Bitmap.CompressFormat.PNG, 100, stream)

        // Flush the stream
        stream.flush()

        // Close stream
        stream.close()
    } catch (e: IOException){ // Catch the exception
        e.printStackTrace()
    }

    // Return the saved image uri
    return Uri.parse(file.absolutePath)
}
xml/provider_paths.xml

<?xml version="1.0" encoding="utf-8"?>
<paths>
    <cache-path name="images" path="."/>
</paths>
AndroidManifest.xml

<?xml version="1.0" encoding="utf-8"?>
<manifest
    xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:tools="http://schemas.android.com/tools"
    package="com.cfsuman.jetpackexamples"
    >

    <application
        android:allowBackup="true"
        android:fullBackupContent="true"
        android:icon="@mipmap/ic_launcher"
        android:label="@string/app_name"
        android:roundIcon="@mipmap/ic_launcher_round"
        android:supportsRtl="true"
        android:theme="@style/AppTheme"
        tools:ignore="GoogleAppIndexingWarning">
        <activity android:name=".MainActivity">
            <intent-filter>
                <action android:name="android.intent.action.MAIN" />

                <category android:name="android.intent.category.LAUNCHER" />
            </intent-filter>
        </activity>

        <provider
            android:name="androidx.core.content.FileProvider"
            android:authorities="${applicationId}.provider"
            android:exported="false"
            android:grantUriPermissions="true">
            <meta-data
                android:name="android.support.FILE_PROVIDER_PATHS"
                android:resource="@xml/provider_paths"/>
        </provider>
    </application>

</manifest>
