Friday, April 13, 2018

android kotlin - Compress bitmap example

MainActivity.kt

package com.cfsuman.kotlinexamples

import android.content.Context
import android.support.v7.app.AppCompatActivity
import android.os.Bundle
import kotlinx.android.synthetic.main.activity_main.*
import android.graphics.Bitmap
import android.graphics.drawable.BitmapDrawable
import android.support.v4.content.ContextCompat
import android.widget.Toast
import android.graphics.BitmapFactory
import java.io.*


class MainActivity : AppCompatActivity() {

    override fun onCreate(savedInstanceState: Bundle?) {
        super.onCreate(savedInstanceState)
        setContentView(R.layout.activity_main)

        // Get the bitmap from given drawable object
        val drawable = ContextCompat.getDrawable(applicationContext,R.drawable.tulip)
        val bitmap = (drawable as BitmapDrawable).bitmap

        // Click listener for button widget
        button.setOnClickListener{
            // Compress bitmap and display into image view
            image_view_compressed.setImageBitmap(compressBitmap(bitmap,5))

            toast("Bitmap compressed with 5% quality.")
        }
    }


    // Method to compress a bitmap
    private fun compressBitmap(bitmap:Bitmap, quality:Int):Bitmap{
        // Initialize a new ByteArrayStream
        val stream = ByteArrayOutputStream()

        /*
            **** reference source developer.android.com ***

            public boolean compress (Bitmap.CompressFormat format, int quality, OutputStream stream)
                Write a compressed version of the bitmap to the specified outputstream.
                If this returns true, the bitmap can be reconstructed by passing a
                corresponding inputstream to BitmapFactory.decodeStream().

                Note: not all Formats support all bitmap configs directly, so it is possible
                that the returned bitmap from BitmapFactory could be in a different bitdepth,
                and/or may have lost per-pixel alpha (e.g. JPEG only supports opaque pixels).

                Parameters
                format : The format of the compressed image
                quality : Hint to the compressor, 0-100. 0 meaning compress for small size,
                    100 meaning compress for max quality. Some formats,
                    like PNG which is lossless, will ignore the quality setting
                stream: The outputstream to write the compressed data.

                Returns
                    true if successfully compressed to the specified stream.


            Bitmap.CompressFormat
                Specifies the known formats a bitmap can be compressed into.

                    Bitmap.CompressFormat  JPEG
                    Bitmap.CompressFormat  PNG
                    Bitmap.CompressFormat  WEBP
        */

        // Compress the bitmap with JPEG format and quality 50%
        bitmap.compress(Bitmap.CompressFormat.JPEG, quality, stream)

        val byteArray = stream.toByteArray()

        // Finally, return the compressed bitmap
        return BitmapFactory.decodeByteArray(byteArray, 0, byteArray.size)
    }
}


// Extension function to show toast message
fun Context.toast(message: String) {
    Toast.makeText(this, message, Toast.LENGTH_SHORT).show()
}
activity_main.xml

<?xml version="1.0" encoding="utf-8"?>
<LinearLayout
    xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:tools="http://schemas.android.com/tools"
    xmlns:app="http://schemas.android.com/apk/res-auto"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    android:id="@+id/root_layout"
    android:background="#ded5d2"
    android:padding="16dp"
    android:orientation="vertical"
    >
    <ImageView
        android:id="@+id/image_view_source"
        android:layout_width="match_parent"
        android:layout_height="250dp"
        android:src="@drawable/tulip"
        />
    <Button
        android:id="@+id/button"
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:text="Compressed The Bitmap"
        android:layout_gravity="center_horizontal"
        android:layout_margin="10dp"
        />
    <ImageView
        android:id="@+id/image_view_compressed"
        android:layout_width="match_parent"
        android:layout_height="250dp"
        />
</LinearLayout>
