Tuesday, February 6, 2018

android kotlin - RadioGroup and RadioButton example

MainActivity.kt

package com.cfsuman.kotlinexamples

import android.support.v7.app.AppCompatActivity
import android.os.Bundle
import android.view.View
import android.widget.*
import kotlinx.android.synthetic.main.activity_main.*
import android.widget.RadioGroup



class MainActivity : AppCompatActivity() {

    override fun onCreate(savedInstanceState: Bundle?) {
        super.onCreate(savedInstanceState)
        setContentView(R.layout.activity_main)

        // Get radio group selected item using on checked change listener
        radio_group.setOnCheckedChangeListener(
                RadioGroup.OnCheckedChangeListener { group, checkedId ->
                    val radio: RadioButton = findViewById(checkedId)
                    Toast.makeText(applicationContext," On checked change : ${radio.text}",
                            Toast.LENGTH_SHORT).show()
        })


        // Get radio group selected status and text using button click event
        button.setOnClickListener{
            // Get the checked radio button id from radio group
            var id: Int = radio_group.checkedRadioButtonId
            if (id!=-1){ // If any radio button checked from radio group
                // Get the instance of radio button using id
                val radio:RadioButton = findViewById(id)
                Toast.makeText(applicationContext,"On button click : ${radio.text}",
                        Toast.LENGTH_SHORT).show()
            }else{
                // If no radio button checked in this radio group
                Toast.makeText(applicationContext,"On button click : nothing selected",
                        Toast.LENGTH_SHORT).show()
            }
        }
   }


    // Get the selected radio button text using radio button on click listener
    fun radio_button_click(view: View){
        // Get the clicked radio button instance
        val radio: RadioButton = findViewById(radio_group.checkedRadioButtonId)
        Toast.makeText(applicationContext,"On click : ${radio.text}",
                Toast.LENGTH_SHORT).show()
    }
}
activity_main.xml

<?xml version="1.0" encoding="utf-8"?>
<LinearLayout
    xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:tools="http://schemas.android.com/tools"
    android:id="@+id/root_layout"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    android:orientation="vertical"
    android:padding="16dp"
    >
    <RadioGroup
        android:id="@+id/radio_group"
        android:layout_width="match_parent"
        android:layout_height="wrap_content"
        android:background="#dbeceb"
        android:padding="15dp"
        >
        <TextView
            android:id="@+id/title"
            android:layout_width="match_parent"
            android:layout_height="wrap_content"
            android:text="Which is your favorite color?"
            android:textStyle="bold"
            android:textSize="20sp"
            />
        <RadioButton
            android:id="@+id/red"
            android:layout_width="wrap_content"
            android:layout_height="wrap_content"
            android:text="RED"
            android:onClick="radio_button_click"
            />
        <RadioButton
            android:id="@+id/green"
            android:layout_width="wrap_content"
            android:layout_height="wrap_content"
            android:text="GREEN"
            android:onClick="radio_button_click"
            />
        <RadioButton
            android:id="@+id/yellow"
            android:layout_width="wrap_content"
            android:layout_height="wrap_content"
            android:text="YELLOW"
            android:onClick="radio_button_click"
            />
        <RadioButton
            android:id="@+id/pink"
            android:layout_width="wrap_content"
            android:layout_height="wrap_content"
            android:text="PINK"
            android:onClick="radio_button_click"
            />
    </RadioGroup>

    <Button
        android:id="@+id/button"
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:text="Get Selected Color"
        />
</LinearLayout>
