android kotlin - Create view programmatically

MainActivity.kt

package com.cfsuman.kotlinexamples

import android.graphics.Color
import android.graphics.Typeface
import android.support.v7.app.AppCompatActivity
import android.os.Bundle
import android.util.TypedValue
import android.widget.LinearLayout.LayoutParams
import android.widget.TextView
import android.widget.Toast
import kotlinx.android.synthetic.main.activity_main.*

class MainActivity : AppCompatActivity() {

    override fun onCreate(savedInstanceState: Bundle?) {
        super.onCreate(savedInstanceState)
        setContentView(R.layout.activity_main)

        // Variable for counting text view
        var counter: Int = 1;

        // Set a click listener for button widget
        button.setOnClickListener{
            // Create a new TextView instance programmatically
            val text_view: TextView = TextView(this)

            // Creating a LinearLayout.LayoutParams object for text view
            var params : LayoutParams = LayoutParams(
                    LayoutParams.MATCH_PARENT, // This will define text view width
                    LayoutParams.WRAP_CONTENT // This will define text view height
            )

            // Add margin to the text view
            params.setMargins(10,10,10,10)

            // Now, specify the text view width and height (dimension)
            text_view.layoutParams = params

            // Display some text on the newly created text view
            text_view.text = "Hi, i am a TextView. Number : $counter"

            // Set the text view font/text size
            text_view.setTextSize(TypedValue.COMPLEX_UNIT_SP,30F)

            // Set the text view text color
            text_view.setTextColor(Color.RED)

            // Make the text viw text bold italic
            text_view.setTypeface(text_view.typeface,Typeface.BOLD_ITALIC)

            // Change the text view font
            text_view.setTypeface(Typeface.MONOSPACE)

            // Change the text view background color
            text_view.setBackgroundColor(Color.YELLOW)

            // Put some padding on text view text
            text_view.setPadding(50,10,10,10)

            // Set a click listener for newly generated text view
            text_view.setOnClickListener{
                Toast.makeText(this,text_view.text,Toast.LENGTH_SHORT).show()
            }

            // Finally, add the text view to the view group
            root_layout.addView(text_view)

            // Increment the counter
            counter++
        }
    }
}
activity_main.xml

<?xml version="1.0" encoding="utf-8"?>
<LinearLayout
    xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:tools="http://schemas.android.com/tools"
    android:id="@+id/root_layout"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    android:orientation="vertical"
    android:padding="16dp"
    >
    <Button
        android:id="@+id/button"
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:text="Create TextView"
        />
</LinearLayout>
