android - How to create a CardView programmatically

activity_main.xml

<?xml version="1.0" encoding="utf-8"?>
<RelativeLayout
    xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:tools="http://schemas.android.com/tools"
    android:id="@+id/rl"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    android:padding="16dp"
    tools:context=".MainActivity"
    android:background="#ffffff"
    >
    <Button
        android:id="@+id/btn"
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:text="Create A CardView"
        android:layout_alignParentBottom="true"
        android:layout_alignParentRight="true"
        android:layout_alignParentEnd="true"
        />
</RelativeLayout>
MainActivity.java

package com.cfsuman.me.androidcode;

import android.content.Context;
import android.graphics.Color;
import android.graphics.drawable.ColorDrawable;
import android.support.v7.app.AppCompatActivity;
import android.os.Bundle;
import android.support.v7.widget.CardView;
import android.util.TypedValue;
import android.view.View;
import android.view.Window;
import android.widget.Button;
import android.widget.RelativeLayout;
import android.widget.LinearLayout.LayoutParams;
import android.widget.TextView;


public class MainActivity extends AppCompatActivity {
    private Context mContext;

    RelativeLayout mRelativeLayout;
    private Button mButton;


    @Override
    protected void onCreate(Bundle savedInstanceState) {
        // Request window feature action bar
        requestWindowFeature(Window.FEATURE_ACTION_BAR);
        super.onCreate(savedInstanceState);
        setContentView(R.layout.activity_main);

        // Get the application context
        mContext = getApplicationContext();

        // Change the action bar color
        getSupportActionBar().setBackgroundDrawable(new ColorDrawable(Color.BLUE));

        // Get the widgets reference from XML layout
        mRelativeLayout = (RelativeLayout) findViewById(R.id.rl);
        mButton = (Button) findViewById(R.id.btn);

        mButton.setOnClickListener(new View.OnClickListener() {
            @Override
            public void onClick(View view) {
                // Initialize a new CardView
                CardView card = new CardView(mContext);

                // Set the CardView layoutParams
                LayoutParams params = new LayoutParams(
                        LayoutParams.WRAP_CONTENT,
                        LayoutParams.WRAP_CONTENT
                );
                card.setLayoutParams(params);

                // Set CardView corner radius
                card.setRadius(9);

                // Set cardView content padding
                card.setContentPadding(15, 15, 15, 15);

                // Set a background color for CardView
                card.setCardBackgroundColor(Color.parseColor("#FFC6D6C3"));

                // Set the CardView maximum elevation
                card.setMaxCardElevation(15);

                // Set CardView elevation
                card.setCardElevation(9);

                // Initialize a new TextView to put in CardView
                TextView tv = new TextView(mContext);
                tv.setLayoutParams(params);
                tv.setText("CardView\nProgrammatically");
                tv.setTextSize(TypedValue.COMPLEX_UNIT_DIP, 30);
                tv.setTextColor(Color.RED);

                // Put the TextView in CardView
                card.addView(tv);

                // Finally, add the CardView in root layout
                mRelativeLayout.addView(card);
            }
        });
   }
}
build.gradle [dependencies]

compile 'com.android.support:cardview-v7:23.0.1'
