How to set ImageView image from Assets in Android

activity_main.xml

<RelativeLayout
    xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:tools="http://schemas.android.com/tools"
    android:id="@+id/rl"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    android:padding="10dp"
    tools:context=".MainActivity"
    android:background="#c4e8cb"
    >
    <Button
        android:id="@+id/btn"
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:text="Set ImageView Image From Assets"
        />
    <ImageView
        android:id="@+id/iv"
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:padding="5dp"
        android:layout_margin="10dp"
        android:layout_below="@id/btn"
        />
</RelativeLayout>
MainActivity.java

package com.cfsuman.me.androidcodesnippets;

import android.graphics.BitmapFactory;
import android.os.Bundle;
import android.app.Activity;
import android.view.View;
import android.widget.Button;
import android.widget.ImageView;
import android.widget.RelativeLayout;
import android.graphics.Bitmap;
import android.content.res.AssetManager;
import java.io.InputStream;
import java.io.IOException;


public class MainActivity extends Activity {

    @Override
    protected void onCreate(Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);
        setContentView(R.layout.activity_main);

        // Get the widgets reference from XML layout
        final RelativeLayout rl = (RelativeLayout) findViewById(R.id.rl);
        Button btn = (Button) findViewById(R.id.btn);
        final ImageView iv = (ImageView) findViewById(R.id.iv);

        // String variable to hold specified image file name
        final String imageFileName = "animals.png";

        btn.setOnClickListener(new View.OnClickListener() {
            @Override
            public void onClick(View v) {
                // Set ImageView image from Assets folder
                iv.setImageBitmap(getBitmapFromAssets(imageFileName));
            }
        });
  }

    // Custom method to get assets folder image as bitmap
    private Bitmap getBitmapFromAssets(String fileName){
        /*
            AssetManager
                Provides access to an application's raw asset files.
        */

        /*
            public final AssetManager getAssets ()
                Retrieve underlying AssetManager storage for these resources.
        */
        AssetManager am = getAssets();
        InputStream is = null;
        try{
            /*
                public final InputStream open (String fileName)
                    Open an asset using ACCESS_STREAMING mode. This provides access to files that
                    have been bundled with an application as assets -- that is,
                    files placed in to the "assets" directory.

                    Parameters
                        fileName : The name of the asset to open. This name can be hierarchical.
                    Throws
                        IOException
            */
            is = am.open(fileName);
        }catch(IOException e){
            e.printStackTrace();
        }

        /*
            BitmapFactory
                Creates Bitmap objects from various sources, including files, streams, and byte-arrays.
        */

        /*
            public static Bitmap decodeStream (InputStream is)
                Decode an input stream into a bitmap. If the input stream is null, or cannot
                be used to decode a bitmap, the function returns null. The stream's
                position will be where ever it was after the encoded data was read.

                Parameters
                    is : The input stream that holds the raw data to be decoded into a bitmap.
                Returns
                    The decoded bitmap, or null if the image data could not be decoded.
        */
        Bitmap bitmap = BitmapFactory.decodeStream(is);
        return bitmap;
    }
}
